Factories

Pick a factory type, then tap a number on the section to see the materials for the roof, floor, column and machine bases, and underground tanks.

Factory for lease Factory requiring FM Approval

Factory for lease

Factories and warehouses with metal roofs and concrete floors.

Tap a number on the drawing to see the materials

HDPE / TPO sheet membrane
Floor hardener
Non-shrink grout
Polymer-modified cementitious
Liquid polyurethane / polyurea membrane
Exterior wall waterproof coating

Click a number on the drawing to see the materials at that location

Metal roof

Keshun Aquaprufe APF-D100Self-adhesive TPO membrane · Per TDS; dedicated primer 0.20–0.30 kg/m²

Or: Keshun Aquacoat 680, Keshun Aquaprufe TPO
Layers and consumption
1. Butyl self-adhesive TPO membrane – Keshun Aquaprufe APF-D100: Per TDS; dedicated primer 0.20–0.30 kg/m²
Alternatives: Keshun Aquacoat 680 – Exposed polyurethane (per TDS: concrete and metal roofs); Keshun Aquaprufe TPO – Exposed TPO roofing membrane; type P mechanically fastened (per Keshun catalogue).

Top of the roof sheeting. Basis: the manufacturer's technical data sheet (TDS). See roof & terrace waterproofing
Factory floor

Buildmix Hardener Floor-TopDry-shake floor hardener · 4–6 kg/m²

Or: Buildmix Mirror PLAN
Layers and consumption
1. Dry-shake hardener broadcast onto fresh concrete – Buildmix Hardener Floor-Top: Per TDS: 4.0 kg/m² (light/medium duty); 6 kg/m² (heavy duty)
Alternatives: Buildmix Mirror PLAN – Self-levelling underlayment (per TDS: levelling floors before finishing).

Concrete floor surface. Basis: the manufacturer's technical data sheet (TDS).
Steel column bases, machine bases

Buildmix Grout M40 / M60 / M80Non-shrink grout · Per TDS: about 76 bags of 25 kg per 1 m³ of grout
Layers and consumption
1. Non-shrink grout – Buildmix Grout M40 / M60 / M80: Per TDS: about 76 bags of 25 kg per 1 m³ of grout
Gap between base plate and foundation. Basis: the manufacturer's technical data sheet (TDS).
Bathrooms

Buildmix Grout M40 / M60 / M80Non-shrink grout around pipe penetrations · Per detail drawings
Buildmix PolylasticReinforcing mesh at details · 0.8 kg/m²
Buildmix PolylasticWaterproof floor and upstands · 1.6 kg/m² · 2 coats

Or: Keshun Aquaflex KS-988A, Keshun Aquacoat KS-929C
Layers and consumption
1. Pack around pipe penetrations with non-shrink grout, seal with PU sealant; form coving at wall bases with repair mortar – Buildmix Grout M40 / M60 / M80: Per detail drawings
2. Waterproofing coat with reinforcing mesh at corners and pipe penetrations – Buildmix Polylastic: 0.8 kg/m² in 1 coat
3. Waterproofing of the whole floor and wall upstands – Buildmix Polylastic: 1.6 kg/m² in 2 coats
4. Screed and finishes: Per architectural drawings
Alternatives: Keshun Aquaflex KS-988A – Keshun acrylic polymer-cementitious waterproofing (per TDS: bathrooms, balconies, wet areas); Keshun Aquacoat KS-929C – Polyurethane membrane (per TDS: kitchens, bathrooms, balconies).

Floor and wall upstands, under the screed and tiling. Basis: VNA's set of standard waterproofing detail drawings. See bathroom & balcony waterproofing
Exterior walls

Keshun XS-505UV-resistant waterproof coating · Per TDS: 2.0 kg/m² per 1 mm film

Or: Buildmix Wallcoat UV-Flex
Layers and consumption
1. Water-based, UV-resistant waterproof coating – Keshun XS-505: Per TDS: 2.0 kg/m² per 1 mm film
Alternatives: Buildmix Wallcoat UV-Flex – Elastomeric waterproof coating (per TDS: 0.3 kg/m² per coat).

External wall face, exposed. Basis: the manufacturer's technical data sheet (TDS).
Fire-fighting water tank

Buildmix Waterstop PVCWaterstop at joints · V20 / V25
Buildmix LatexBonding slurry · Per TDS
Buildmix PolylasticReinforcing mesh at details · 0.8 kg/m²
Buildmix PolylasticWaterproof base and walls · 2.4 kg/m² · 3 coats

Or: Keshun Aquaflex KS-988A, Keshun Aquaflex KS-168N, Buildmix EP 202W
Layers and consumption
1. Waterstop at construction joints – Buildmix Waterstop PVC: V20 / V25
2. Cement-latex bonding slurry – Buildmix Latex: Per TDS
3. Waterproofing coat with reinforcing mesh at corners and penetrations – Buildmix Polylastic: 0.8 kg/m² in 1 coat
4. Waterproofing of tank base and walls – Buildmix Polylastic: 2.4 kg/m² in 3 coats
5. Protective render or tiling (required over Polylastic): Per architectural drawings
Alternatives: Keshun Aquaflex KS-988A – Acrylic polymer-cementitious type III (per TDS: pools, water tanks); needs a protective render or tiling; Keshun Aquaflex KS-168N – Immersion-grade polymer-cementitious (per TDS: pools, water tanks, fire-fighting reservoirs); Buildmix EP 202W – Water-based epoxy coating — serves as the finish, no protection layer needed.

Internal face of tank base and walls. Basis: VNA's set of standard waterproofing detail drawings.
Wastewater treatment tank

Buildmix Waterstop PVCWaterstop at joints · V20 / V25
Keshun FL1101Epoxy primer · 0.2 kg/m²
Keshun Aquacoat KS-20Spray polyurea · 2.4 kg/m² · 2 mm film

Or: Buildmix EP 202W, Buildmix Epoxy Tar
Layers and consumption
1. Waterstop at construction joints – Buildmix Waterstop PVC: V20 / V25
2. Epoxy primer – Keshun FL1101: 0.2 kg/m²
3. Spray-applied polyurea coating – Keshun Aquacoat KS-20: Per TDS: 2.4 kg/m² for a 2 mm film
Alternatives: Buildmix EP 202W – Water-based epoxy coating (per TDS: treatment and septic tanks; 0.5 kg/m² in 2 coats); Buildmix Epoxy Tar – Coal-tar epoxy anticorrosive coating (per TDS: storage tanks, sewer pipes; not for drinking-water tanks).

Internal face of tank base and walls. Basis: VNA's set of standard waterproofing detail drawings.

Request a consultation – Factory for lease

Factory requiring FM Approval

The roof uses the Aquaprufe TPO membrane, shown with the FM Approved mark in the Keshun catalogue. VNA provides certificates on request.

Tap a number on the drawing to see the materials

HDPE / TPO sheet membrane
Floor hardener
Non-shrink grout
Polymer-modified cementitious
Liquid polyurethane / polyurea membrane
Exterior wall waterproof coating

Click a number on the drawing to see the materials at that location

Roof requiring FM Approval

Keshun Aquaprufe TPOTPO roofing membrane, heat-welded seams · Type P mechanically fastened; type L fully adhered to concrete decks; type H for single-ply roofs and details
Layers and consumption
1. TPO roofing membrane, heat-welded seams – Keshun Aquaprufe TPO: Type P mechanically fastened; type L fully adhered to concrete decks; type H for single-ply roofs and details
Top of the roof, fully exposed. Basis: the manufacturer's product catalogue. See roof & terrace waterproofing
Factory floor

Buildmix Hardener Floor-TopDry-shake floor hardener · 4–6 kg/m²

Or: Buildmix Mirror PLAN
Layers and consumption
1. Dry-shake hardener broadcast onto fresh concrete – Buildmix Hardener Floor-Top: Per TDS: 4.0 kg/m² (light/medium duty); 6 kg/m² (heavy duty)
Alternatives: Buildmix Mirror PLAN – Self-levelling underlayment (per TDS: levelling floors before finishing).

Concrete floor surface. Basis: the manufacturer's technical data sheet (TDS).
Steel column bases, machine bases

Buildmix Grout M40 / M60 / M80Non-shrink grout · Per TDS: about 76 bags of 25 kg per 1 m³ of grout
Layers and consumption
1. Non-shrink grout – Buildmix Grout M40 / M60 / M80: Per TDS: about 76 bags of 25 kg per 1 m³ of grout
Gap between base plate and foundation. Basis: the manufacturer's technical data sheet (TDS).
Bathrooms

Buildmix Grout M40 / M60 / M80Non-shrink grout around pipe penetrations · Per detail drawings
Buildmix PolylasticReinforcing mesh at details · 0.8 kg/m²
Buildmix PolylasticWaterproof floor and upstands · 1.6 kg/m² · 2 coats

Or: Keshun Aquaflex KS-988A, Keshun Aquacoat KS-929C
Layers and consumption
1. Pack around pipe penetrations with non-shrink grout, seal with PU sealant; form coving at wall bases with repair mortar – Buildmix Grout M40 / M60 / M80: Per detail drawings
2. Waterproofing coat with reinforcing mesh at corners and pipe penetrations – Buildmix Polylastic: 0.8 kg/m² in 1 coat
3. Waterproofing of the whole floor and wall upstands – Buildmix Polylastic: 1.6 kg/m² in 2 coats
4. Screed and finishes: Per architectural drawings
Alternatives: Keshun Aquaflex KS-988A – Keshun acrylic polymer-cementitious waterproofing (per TDS: bathrooms, balconies, wet areas); Keshun Aquacoat KS-929C – Polyurethane membrane (per TDS: kitchens, bathrooms, balconies).

Floor and wall upstands, under the screed and tiling. Basis: VNA's set of standard waterproofing detail drawings. See bathroom & balcony waterproofing
Exterior walls

Keshun XS-505UV-resistant waterproof coating · Per TDS: 2.0 kg/m² per 1 mm film

Or: Buildmix Wallcoat UV-Flex
Layers and consumption
1. Water-based, UV-resistant waterproof coating – Keshun XS-505: Per TDS: 2.0 kg/m² per 1 mm film
Alternatives: Buildmix Wallcoat UV-Flex – Elastomeric waterproof coating (per TDS: 0.3 kg/m² per coat).

External wall face, exposed. Basis: the manufacturer's technical data sheet (TDS).
Fire-fighting water tank

Buildmix Waterstop PVCWaterstop at joints · V20 / V25
Buildmix LatexBonding slurry · Per TDS
Buildmix PolylasticReinforcing mesh at details · 0.8 kg/m²
Buildmix PolylasticWaterproof base and walls · 2.4 kg/m² · 3 coats

Or: Keshun Aquaflex KS-988A, Keshun Aquaflex KS-168N, Buildmix EP 202W
Layers and consumption
1. Waterstop at construction joints – Buildmix Waterstop PVC: V20 / V25
2. Cement-latex bonding slurry – Buildmix Latex: Per TDS
3. Waterproofing coat with reinforcing mesh at corners and penetrations – Buildmix Polylastic: 0.8 kg/m² in 1 coat
4. Waterproofing of tank base and walls – Buildmix Polylastic: 2.4 kg/m² in 3 coats
5. Protective render or tiling (required over Polylastic): Per architectural drawings
Alternatives: Keshun Aquaflex KS-988A – Acrylic polymer-cementitious type III (per TDS: pools, water tanks); needs a protective render or tiling; Keshun Aquaflex KS-168N – Immersion-grade polymer-cementitious (per TDS: pools, water tanks, fire-fighting reservoirs); Buildmix EP 202W – Water-based epoxy coating — serves as the finish, no protection layer needed.

Internal face of tank base and walls. Basis: VNA's set of standard waterproofing detail drawings.
Wastewater treatment tank

Buildmix Waterstop PVCWaterstop at joints · V20 / V25
Keshun FL1101Epoxy primer · 0.2 kg/m²
Keshun Aquacoat KS-20Spray polyurea · 2.4 kg/m² · 2 mm film

Or: Buildmix EP 202W, Buildmix Epoxy Tar
Layers and consumption
1. Waterstop at construction joints – Buildmix Waterstop PVC: V20 / V25
2. Epoxy primer – Keshun FL1101: 0.2 kg/m²
3. Spray-applied polyurea coating – Keshun Aquacoat KS-20: Per TDS: 2.4 kg/m² for a 2 mm film
Alternatives: Buildmix EP 202W – Water-based epoxy coating (per TDS: treatment and septic tanks; 0.5 kg/m² in 2 coats); Buildmix Epoxy Tar – Coal-tar epoxy anticorrosive coating (per TDS: storage tanks, sewer pipes; not for drinking-water tanks).

Internal face of tank base and walls. Basis: VNA's set of standard waterproofing detail drawings.

Request a consultation – Factory requiring FM Approval

Illustrative sections. Systems follow VNA's standard waterproofing detail drawings and the manufacturers' TDS; the final selection follows the project's design documents.

How VNA supports your project

System proposalsbased on your drawings and site conditions
Submittal dossiersTDS and test reports ready in the technical library
Waterproofing detail drawingsPDF and DWG for design teams
Quotations & site guidanceby project quantity and schedule

Warranty: Under VNA's supervision and records, the manufacturer issues a product warranty certificate for the project; the product warranty period is 10 years.
